ISO Certificated resonable price PPR pipe fittings unequal tee/ppr fittings tee
1.Good chemicals and drugs resistance
2.Strong mechanical strength
3.Good electrical insulation,Simple installat
script>
script>
script>
script>
script>
script>
1. PPR Pipe Fittings Unequal Tee
SWIN PPR Pipe Fittings Unequal Tee are made of Polypropylene Random Copolymer (PP-R), The quality of our material guarantees long life over 10 years, high resistance to pressure and temperature. This material is suitable for hot and cold water supply systems and heating systems.
| Socket Socket | 90 °C Elbow | 45°C Elbow | Equal Tee | Female Plastic Loose Joint |
| Male Plastic Loose Joint | Bypass Bend | Unequal Tee | Reducing Elbow | Female Thread union |
| Stop Valve | Brass Ball Valve | 4-Way Straight Cross | Male Thread Union | 90°C Female Elbow |
| Female Tee | Male Losse Joint | 90°C Male Elbow | Male Tee | Femal Loose Joint |
| Reducing Couping | Seated Male Elbow | Seated Female Elbow | Clip | Plastic Ball Valve |
| Plastic Flange | Male Plug | Pipe Cap | Swan Neck | Adjustable Clip |
| Double union Ball Valve | Plastic Flange Plate | Heat Melting Machine | Melting Joint | Scissors |
2. PPR Pipe Fittings Unequal Tee Avalible Size De
SWIN PPR Pipe Fittings Unequal Tee can be used for Hot and cold water application, for transportation of all kinds of liquid foods,
for piping system in Industries like transportation of aggressive fluids (acids, chemicals, alkalis etc.) and for conveying compressed air. One of the best advantages is its simple instalment. Its 5-7 times faster compare to steel pipes.
| Specification | Packing(pcs/box) |
| TD25X20X25 | 54 |
| TD32X20X32 | 40 |
| TD32X25X32 | 32 |
| TD40X20X40 | 24 |
| TD40X25X40 | 24 |
| TD40X32X40 | 36 |
| TD50X20X50 | 33 |
| TD50X25X50 | 33 |
| TD50X25X50 | 30 |
| TD50X32X50 | 24 |
| TD50X40X50 | 20 |
| TD63X20X63 | 15 |
| TD63X25X63 | 15 |
| TD63X32X63 | 15 |
| TD63X40X63 | 12 |
| TD63X50X63 | 12 |
| TD75X25X75 | 12 |
| TD75X32X75 | 10 |
| TD75X40X75 | 8 |
| TD75X50X75 | 8 |
| TD75X63X75 | 6 |
| TD90X25X90 | 6 |
| TD90X32X90 | 6 |
| TD90X40X90 | 6 |
| TD90X50X90 | 4 |
| TD90X63X90 | 3 |
| TD90X75X90 | 3 |
| TD110X25X110 | 4 |
| TD110X32X110 | 1 |
| TD110X40X110 | 1 |
| TD110X50X110 | 1 |
| TD110X63X110 | 1 |
| TD110X75X110 | 1 |
MORE DE
1. High Temperature Resistance: the maximum sustained working temperature is up to 70 Degrees Celsius, the maximum transient temperature is up to 95 Degrees Celsius.
2. Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe.
3. Non-toxic: no heavy metal additives would not be covered with dirt or contaminated by bacterium.
4. Corrosion Resistant: resist chemical matters or electron chemical corrosion.
5. Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system.
6. Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes.
7. Long Life: more than 50 years under normal conditions.
8. Recycled and Environment-friendly.
